Stacked bar chart emails send Week on Week

SOLVE

Hi,



We send out different email campaigns and also have several workflow running that send out emails. We manage our marketing efforts on weekly basis. Is it possible to create a stacked bar chart that displays the total number of send emails from all campaigns and workflow Week on Week? The stacked bar consists of the different emails that were send out.



Thanks and regards Rens

0 Upvotes
1 Accepted solution
colinwitt
Solution
Top Contributor | Gold Partner
Top Contributor | Gold Partner

Stacked bar chart emails send Week on Week

SOLVE

Hi @RensV,

yes, this should be possible with the custom report builder.

  • Create a new custom report and select "Marketing E-Mails" and "Marketing E-Mail Analytics" as additional data sources.
  • Use "email name" as the break down, "send date" as the x-axis and "marketing email sent" as the y-axis
  • Click the little pen icon on the x-axis "send date" to change the frequency to "weekly"
  • Go to the "Configure" tab to change the overall time period or add additional filters



You should get something like this:

email report.png



Let me know if this helps or if you have any questions.



Best
Colin



Leadwunder

View solution in original post

2 Replies 2
RensV
Participant

Stacked bar chart emails send Week on Week

SOLVE

Hi @colinwitt ,



This is just perfect 🙏!



Thank you for the clear step by steps, the report was done under 60 seconds. I just don't have any additonal questions, this is the end result I was looking for.



Great community and thanks for your support!

colinwitt
Solution
Top Contributor | Gold Partner
Top Contributor | Gold Partner

Stacked bar chart emails send Week on Week

SOLVE

Hi @RensV,

yes, this should be possible with the custom report builder.

  • Create a new custom report and select "Marketing E-Mails" and "Marketing E-Mail Analytics" as additional data sources.
  • Use "email name" as the break down, "send date" as the x-axis and "marketing email sent" as the y-axis
  • Click the little pen icon on the x-axis "send date" to change the frequency to "weekly"
  • Go to the "Configure" tab to change the overall time period or add additional filters



You should get something like this:

email report.png



Let me know if this helps or if you have any questions.



Best
Colin



Leadwunder
